Tapping Machine Automatic HT2-223

Tapping Machine Automatic HT2-223

Tapping Machine Kuala Lumpur (KL)
Tapping Machine Selangor
Tapping Machine Malaysia

Product Description

Tapping Machine Automatic HT2-223 is made with following good points:
  1. A classic and popular model which is used very often in specialized machines.(Horizontal model is available.)
  2. Quality made in Taiwan.
Video displays please see : https://goo.gl/uQZZOJ

Specification Table
Specifications / Model HD-AT12 HD-AT19 HT1-203 HT2-223 HT3-231
Stroke Automatic Automatic Automatic Automatic Automatic
Spindle Type Inside Spindle MT2 MT3 X MT2 MT3
For Chuck JT6 JT6 JT2 JT6 JT6
Working Ability Steel (S45C) 3-13 5-20 2-8 5-16 10-32
Spindle Travel (mm) 93 133 45 65 65
Motor 1HP-4P 2HP-6P 1/2HP-4P 1HP-6P 2HP-6P
Spindle Speed
RPM (Steps)		 50HZ 256-1278 (8) 166-829 (6) 420-1340 (3) 155-515 (3) 50-200 (3)
60HZ 308-1534 (8) 200-995 (6) 500-1600 (3) 190-620 (3) 60-240 (3)
Weight (kg) 112 234 97 200 250
  1. The practical working abilities are very related to sharpness on drill bit, good lubrication and suitable cooling.
  2. Customized spindle speed might be required for particular materials or drilling sizes.
